Custom Dual Deck 2x4 RJ45 Connector with Cat6 Speed Performance and Side Entry Mount

Minimum Order Quantity :	1 piece	Price :	Please contact us to get the latest price.
Packaging Details :	Tray in Carton	Delivery Time :	10 days
Payment Terms :	T/T,D/P,D/A,L/C,Western Union,MoneyGram	Supply Ability :	100K pcs/day

Place of Origin:	DongGuan of China	Brand Name:	DGKYD
Certification:	RoHS/CE/UL/FCC/CE/ISO9001/ISO14001	Model Number:	DGKYD24Q077DG1A5D068
Document:	DGKYD24Q077DG1A5D068.pdf

Detail Information
Port Configuration:	Dual Deck 2x4	Speed Performance:	Cat6
Port Orientation:	Side Entry	Mount Type:	Dip/THT
Gender:	Female RJ45	Product Name:	RJ45 Ethernet Connector
Housing Material:	PBT Polyester	Filter:	With Filter
Operation Temperature:	-40°C~+85°C	Storage Temperature:	-40°C~+85°C

Product Description

Custom Integrated RJ45 Jack Dual Deck 2x4 Gigabit Ethernet Connector Technical Grade DGKYD24Q077DG1A5D068

Product Overview

Custom Integrated RJ45 Jack dual deck 2x4 gigabit ethernet connector technical grade DGKYD24Q077DG1A5D068

Part Number: DGKYD24Q077DG1A5D068

Product Documentation: DGKYD24Q077DG1A5D068.pdf

Technical Parameters

Parameter	Value
Part Number	DGKYD24Q077DG1A5D068
Brand	DGKYD/OEM/ODM
Product Type	Connector-Modular
Connector Style	Jack
Jack Type	RJ45
Connector Type	Modular Jack
Latch Style	Standard
Latch	TAB-UP/DOWN
Filter	With Filter
LED Option	With LED
LED Color	Green/Yellow-Green/Yellow
Panel Stops	With Panel Stops
Shielded	With metal shield
Applies To	Printed Circuit Board
Port Configuration	2X4 Port
Number of Positions	10
Jack Configuration	2X4
Terminals per Port	8
Shield Material	Copper Alloy preplated with Nickel
PCB Mounting Orientation	Side Entry (Right Angle)
Contact Mating Area Plating	Gold 6u
Contact Base Material	Phosphor Bronze
Solder Tail Contact Plating Material	Tin-Lead over Nickel
PCB Mounting Style	Through Hole
Termination Method to PC Board	Through Hole-Press-Fit
Board Lock	With/Without Board Lock
Housing Material	PBT Polyester
Housing Color	Black
Housing Material Temperature	Standard
UL Flammability Rating	UL 94V-0

Product Images

Technical Specifications

Interface Type: RJ45 connector for 10/100/1000BASE-T Ethernet
Type: RJ45 with built-in magnetics
Working Frequency: High frequency with filtering and anti-interference characteristics
Working Temperature: -40°C to 85°C
Storage Temperature: -40°C to 85°C
Lead-Free Soldering: Wave soldering height up to 265°C

Manufacturing Capabilities

RJ45 full series of integrated circuit accessories, manufacturer direct supply

Business Mode: Manufacturer
Delivery Time: Approximately two weeks for standard orders
Customization Options:
- LED indicator light (green, yellow, red, orange, blue, bi-color LED)
- Shield with EMI fingers or without
- Coil ratio of magnetic core
- Magnetics circuit diversification options
- Contact gold plating (FU, 3U, 6U, 15u, 30U, 50U)
- Plastic housing material (PBT, PA46, PA9T, LCP)

Our products meet industry standards for electrical properties, mechanical dimensions, and environmental compliance. Your satisfaction is our primary service objective!
