Yellow Color Unshielded Rj45 Modular Jack With Transformer , 100 Base - T
Contact Person : Nicole Zhuo
Phone Number : +86 18925835585
WhatsApp : +8613538542087
| Minimum Order Quantity : | 1 piece | Price : | Please contact us to get the latest price. |
|---|---|---|---|
| Packaging Details : | Tray in Carton | Delivery Time : | 10 days |
| Payment Terms : | T/T, D/P, D/A, L/C, Western Union, MoneyGram | Supply Ability : | 100K pcs/day |
| Place of Origin: | DongGuan of China | Brand Name: | DGKYD |
|---|---|---|---|
| Certification: | RoHS/CE/UL/FCC/CE/ISO9001/ISO14001 | Model Number: | KRJ-109BNL |
|
Detail Information |
|||
| Product Name: | RJ45 With Transformer | Type: | RJ45 Female |
|---|---|---|---|
| Housing: | Phenolic, PBT Black (UL94V-0) | Plastic Core: | Glass Fiber Filler PBT Black(UL94V-0),ROHS |
| Shield RJ45: | Yes | No.Port: | RJ45 Single Port |
| High Light: | rj45 cat6 connector,1 port rj45,10/100baseT RJ45 with transformer |
||
Product Description
| ATTRIBUTE | ATTRIBUTE VALUE |
|---|---|
| TEMPERATURE | -40 to +85℃ |
| SPEED | 10/100BASE |
| SHIELD PLATING MATERIAL | NICKEL |
| SHIELD EMI TABS | YES |
| SHIELD | METAL SHIELD |
| ROHS COMPLIANT | YES |
| PANEL STOP | YES |
| PCB MOUNT ANGLE | RIGHT ANGLE |
| PACKAGE | THT |
| NUMBER OF POSITIONS | 8 |
| NUMBER OF PORTS | RJ45 |
| NUMBER OF CONTACTS | 8 |
| LED OPTION | G/Y |
| LATCH | DOWN |
| HOUSING MATERIAL | PBT UL94V-0 |
| CONTACT MATING AREA PLATING | 6U GOLD PLATING |
| CONNECTOR TYPE | RJ45 |
| CONNECTOR MATERIAL COLOR | BLACK |
RJ45 ,in order to keep good touch between gold finger and crystal head,should paint the gold on the surface,there is 6u,15u,30,50u,usually use 6u,according to customer’s request and cost to proceed, gold finger insert and pull life should be 750 times above.
Applications:
• Integrated RJ45 connector main used to :
• 10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical transceiver,IP phone,internet set-top box,internet camera,net bridge,computer,
telecommunication,MODEM,HomePNA,DSL／ADSL and so on.
