DGKYD311Q070DC2A4DN 25.4mm Network Interface Connector Single Port Gigabit Filter Integrated Transformer 10PIN

Minimum Order Quantity : 1 piece Price : Please contact us to get the latest price.
Packaging Details : Tray in Carton Delivery Time : 10 days
Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram Supply Ability : 100K pcs/day
Place of Origin: DongGuan of China Brand Name: DGKYD
Certification: RoHS/CE/UL/FCC/CE/ISO9001/ISO14001 Model Number: DGKYD311Q070DC2A4DN

Detail Information

Application: PCB Gender: Female
Housing Material: PBT BLACK Contact Mating Area Plating: GOLD 6u'' / 15u"/ 30u"/ 50u" For Optional
Latch: TAB-Up LED Option: With LED
Number Of Ports: 1 Number Of Contacts: 8
PCB Mount Angle: SIDE ENTRY
High Light:

Single Port Gigabit Filter Transformer

,

10PIN Integrated Transformer

,

DGKYD311Q070DC2A4DN

Product Description

DGKYD311Q070DC2A4DN 25.4mm network interface connector single port gigabit filter integrated transformer 10PIN

Specification

Part Number

DGKYD311Q070DC2A4DN

Brand DGKYD/OEM/ODM
Product Type  Connector-Modular Connector Style Jack
Jack Type RJ45 Connector Type  Modular Jack
Latch Style Standard Latch TAB-UP
Filter Without Filter LED Option With LED
LED Color L-Green/R-Yellow Panel Stops With Panel Stops
Shielded With metal shield Applies To  Printedout Circuit Board
Port Configuration  1X1 Ports Number of Positions  10
Jack Configuration 1X1 Terminals per Port 8
Shield Material Copper Alloy preplated with Nickel PCB Mounting Orientation  Side Entry (Right Angle)
Contact Mating Area Plating Gold 6u Contact Base Material  Phosphor Bronze
Solder Tail Contact Plating Material  Tin-Lead over Nickel PCB Mounting Style  Through Hole
Termination Method to PC Board  Through Hole-Press-Fit Board Lock With/Without Board Lock
Housing Material  PBT Polyester Housing Color black
Housing Material  Temperature Standard UL Flammability Rating  UL 94V-0



Performance parameters:

1. Applied to Ethernet, coil ratio: 1CT: 1CT

2. Meet IEEE 802.3 & ANSI X 3.263 standard

3. Open circuit inductance (OCL): 350uH (MIN) @ 100kHz, 0.1VRMS with 8Ma DC Bias

4. Wave soldering process of 265 ℃ Max meeting the requirements of EU ROHS standard

5. Withstand voltage: 2250VDC 1mA max, 60s

6. Impedance: 100 ohms

7. RJ45 interface meets FCC 68.5 standard

8. DC resistance: 1.5 Ω

DGKYD311Q070DC2A4DN 25.4mm Network Interface Connector Single Port Gigabit Filter Integrated Transformer 10PIN 0DGKYD311Q070DC2A4DN 25.4mm Network Interface Connector Single Port Gigabit Filter Integrated Transformer 10PIN 1DGKYD311Q070DC2A4DN 25.4mm Network Interface Connector Single Port Gigabit Filter Integrated Transformer 10PIN 2DGKYD311Q070DC2A4DN 25.4mm Network Interface Connector Single Port Gigabit Filter Integrated Transformer 10PIN 3
