DGKYD59211118AB1A3DY1027 RJ45 Without Filter Socket 10P8C With LED 59 Series Y/G

Name: DGKYD59211118AB1A3DY1027 RJ45 Without Filter Socket 10P8C With LED 59 Series Y/G
Brand: DGKYD
SKU: DGKYD59211118AB1A3DY1027
Rating: 4.6 (173 reviews)

Minimum Order Quantity :	1 piece	Price :	Please contact us to get the latest price.
Packaging Details :	Tray in Carton	Delivery Time :	10 days
Payment Terms :	T/T, D/P, D/A, L/C, Western Union, MoneyGram	Supply Ability :	100K pcs/day

Place of Origin:	DongGuan of China	Brand Name:	DGKYD
Certification:	RoHS/CE/UL/FCC/CE/ISO9001/ISO14001	Model Number:	DGKYD59211118AB1A3DY1027

Detail Information
Product Name:	RJ45 Jack	LEDS/EMI Fingers:	G/Y
Gender:	Female	Application:	Lan,bridge,PC,router,usb Hub Network Rj45
RJ45 Suitable:	For CAT5&6 Ethernet Cable Or UTP	Feature:	Cat5
Working Temperature:	-40°C~+85°C	Storage Temperature:	-40°C~+85°C
Number Of Contacts:	8	PCB Mount Angle:	SIDE ENTRY
High Light:	Y/G RJ45 Jack , 10P8C RJ45 Without Transformer , LED RJ45 Without Transformer

Product Description

DGKYD59211118AB1A3DY1027 RJ45 without filter socket 10P8C with LED 59 series Y/G

DGKYD59211118AB1A3DY1027 RJ45 Without Filter Socket 10P8C With LED 59 Series Y/G 0

Material specifications:

Plastic core:Glass fiber filler PA46 Black(UL94V-0)
Contact:gold pin0.35mm thick phos bronze plated nickel then with G/Fu’gold
PCB Terminal:Phosphor bronze ,Tail-Tin over Nickl
Housing:Phenolic, PA46 Black (UL94V-0)
Metal shell:Copper Alloy ,Tin and Nickel plated

Applications:

• Integrated RJ45 connector main used to :

• 10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,

optical transceiver,IP phone, internet set-top box,internet camera,net bridge,computer,

DGKYD59211118AB1A3DY1027 RJ45 Without Filter Socket 10P8C With LED 59 Series Y/G

Y/G RJ45 Jack

10P8C RJ45 Without Transformer

LED RJ45 Without Transformer
