Metal Shield USB RJ45 Connector With Gigabit Ethernet Transformer

Minimum Order Quantity : 1 piece Price : Please contact us to get the latest price.
Packaging Details : Tray in Carton Delivery Time : 10 days
Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram Supply Ability : 100K pcs/day
Place of Origin: DongGuan of China Brand Name: DGKYD
Certification: RoHS/CE/UL/FCC/CE/ISO9001/ISO14001 Model Number: KRJ-008QGYGUSBNL

Detail Information

Product Name: RJ45 Shielded Connector Feature: Metal Shielded, Pcb MOUNTABLE Rj45 Jack
Rj45 Port Structure: USB 3.0 + RJ45 LED Color: Green & Yellow
Gender: Female Applications: Switch,transceiver,laptop,computer RJ45 And Other Devices
High Light:

KRJ 008QGYGUSBNL USB RJ45 Connector

,

FCC USB RJ45 Connector

,

USB3.0 RJ45 Shielded Connector

Product Description

Metal Shield USB RJ45 Connector With Gigabit Ethernet Transformer



Metal shield stacked USB RJ45 Connector with gigabit ethernet transformer



China manufacturer KRJ-008QGYGUSBNL metal shielded USB RJ45 Connector, cat6, with LEDs

  • Internal magnetics are 100% electrically tested for HI-POT and functionality

  • 350uHminimum OCL with 8mA bias current

  • High performance for maximum EMI suppression

  • Minimum 1500Vrms isolation per IEEE 802.3 requirement

  • ROHS-6 peak wave solder temperature rating 260℃

  • Operating temperarure range :0℃ to +70℃

  • Storage temperature range :-40℃ to +85℃

  • Length:29.0mm

Electrical Specifications at 25℃
.Insertion Loss:1-100MHZ -1.0dBmax
.Rturn Loss:1-30MHZ -16.0dBmin
30-60MHZ -14.0dBmin
60-80MHZ -10.0dBmin
.Cross Talk:1-30MHZ -40.0dBmin
30-60MHZ -35.0dBmin
60-80MHZ -30.0dBmin
.CMR:1-100MHZ -35dBmin
.Hi-pot:1500v AC 6S 1mA
.Turn Ratio:1CT:1CT±3%
.OCL:350uH @100KHZ 100Mv 8mA DC

Applications:
• Integrated RJ45 connector main used to :
• 10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical
transceiver,IP phone, internet set- top box,internet camera,netbridge,computer,telecommunication,
MODEM,HomePNA,DSL/ADSL and so on.
