1x1 single port RJ45 Ethernet Connector 100Mb cat 5 manetic modular jack G/Y led

China 1x1 single port RJ45 Ethernet Connector 100Mb cat 5 manetic modular jack G/Y led supplier

Large Image :  1x1 single port RJ45 Ethernet Connector 100Mb cat 5 manetic modular jack G/Y led

Product Details:

Place of Origin: DongGuan of China
Brand Name: DGKYD
Certification: RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Model Number: KRJ-100SH5NL

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: Please contact us to get the latest price.
Packaging Details: Tray in Carton
Delivery Time: 10 days
Payment Terms: T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability: 100K pcs/day
Detailed Product Description
Product Name: RJ45 Ethernet Connector Gender: Female
Application: Lan,bridge,PC,router,usb Hub Network Rj45, IP Camera RJ45 Suitable: For CAT5&6 Ethernet Cable Or UTP
Feature: High Performance, Integrated Magnetics LEDS/EMI Fingers: For Optional

1x1 single port RJ45 Ethernet Connector 100M cat 5 plug modular rj45

Part Number
KRJ-100SH5NL
Brand
DGKYD/OEM/ODM
Place of Origin
Guangdong of China
Certification
ISO9001/ISO14001/CE /UL/FCC/Reach/RoHS
Product Type 

Connector-Modular

Connector Style
Jack
Jack Type
RJ45
Connector Type 
Modular Jack
Latch Style
Standard
Latch
up
Filter
With Filter
LED Option
G/Y LED
Shielded
Yes
Applies To 
Printed Circuit Board
Performance Speed
10/100/1000/10G BASE-T
Grounding Options
Panel Ground and PCB Ground
Port Configuration 
single port
Number of Positions 
8
Shield Material
Copper Alloy preplated with Nickel
PCB Mounting Orientation 
Side Entry (Right Angle)
Contact Mating Area Plating Material 
Gold 6u/15u/30u/50u
Contact Base Material 
Phosphor Bronze
Solder Tail Contact Plating Material 
Tin-Lead over Nickel
PCB Mounting Style 
Through Hole
Termination Method to PC Board 
Through Hole-Press-Fit
Board Lock
With/Without Board Lock
Housing Material 
PBT Polyester
Housing Color
Black
Housing Material  Temperature
Standard
UL Flammability Rating 
UL 94V-0



  • Internal magnetics are 100% electrically tested for HI-POT and functionality
  • Suitable for CAT5&6 fast Ethernet Cable or better UTP
  • 350uHminimum OCL with 8mA bias current
  • High performance for maximum EMI suppression
  • Minimum 1500Vrms isolation per IEEE 802.3 requirement
  •  ROHS-6 peak wave solder temperature rating 260℃
  • Operating temperarure range : -40℃ to +85℃
  • Storage temperature range : -40℃ to +85℃

1x1 single port RJ45 Ethernet Connector 100Mb cat 5 manetic modular jack G/Y led



Competitive Advantage:

Keyouda has various types of appearance and many kinds of internal schematic products,high quality,

customerfirstly ,100% test, 0 defect, short lead time are our best advantages
