IEEE802.3u 10 / 100 BASE Network RJ45 Modular Connector with power over ethernet

Place of Origin: DongGuan of China Brand Name: DGKYD
Certification: RoHS/CE/UL/FCC/CE/ISO9001/ISO14001 Model Number: KRJ-0101YGZWKNL

Detail Information

Application: Fiber Optic,ip Camera ,dvr,dsl,modem,wifi Etc Feature: Power Over Ethernet
OEM/ODM: Yes Type: Multi Pin Rj45 Magjack
Gender: Rj45 Receptacle Product Name: RJ45 Modular Jack

Product Description

IEEE802.3u 10 / 100 BASE Network RJ45 Modular Connector With Front And Back Pin

Key Features

  • Available for 2.5GBASE-T, 5GBASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T, HDBASE-T Speeds
  • RoHS Compliant
  • Top and Side-Entry PCB Mount Options Available
  • Multiple Package Options Available, 1x1, 1xN, 2xN, RJ45/USB, Low Profile, Offset & more.
  • THT, Press Fit, Pin-In-Paste, SMT Options
  • Higher Isolation (TVSS, Surge)
  • Extended Temperature -40°C to +85°C
  • PoE, PoE+ & 4 Pair PoE Capable



Part Number KRJ-0101YGZWKNL Brand DGKYD/OEM/ODM
Product Type  Connector-Modular Connector Style Jack
Jack Type RJ45 Connector Type  Modular Jack
Latch Style Standard Latch Down
Filter With Filter LED Option Without LED
Shielded Yes Applies To  Printed Circuit Board
Performance Speed 10/100 BASE-TX Grounding Options Panel Ground and PCB Ground
Port Configuration  Single Number of Positions  8
Jack Configuration 1 x 1 Terminals per Port 8
Shield Material Copper Alloy preplated with Nickel PCB Mounting Orientation  Side Entry (Right Angle)
Contact Mating Area Plating Material  Gold 6u/15u/30u/50u Contact Base Material  Phosphor Bronze
Solder Tail Contact Plating Material  Tin-Lead over Nickel PCB Mounting Style  Through Hole
Housing Material  PBT Polyester Housing Color Black
Operation Temperature -40℃ to +85℃ UL Flammability Rating  UL 94V-0
