Extra low frofile RJ45 PCB Connector cat5 Network Port RJ45 with magnetics

China Extra low frofile RJ45 PCB Connector cat5 Network Port RJ45 with magnetics supplier
Extra low frofile RJ45 PCB Connector cat5 Network Port RJ45 with magnetics supplier Extra low frofile RJ45 PCB Connector cat5 Network Port RJ45 with magnetics supplier Extra low frofile RJ45 PCB Connector cat5 Network Port RJ45 with magnetics supplier Extra low frofile RJ45 PCB Connector cat5 Network Port RJ45 with magnetics supplier Extra low frofile RJ45 PCB Connector cat5 Network Port RJ45 with magnetics supplier Extra low frofile RJ45 PCB Connector cat5 Network Port RJ45 with magnetics supplier

Large Image :  Extra low frofile RJ45 PCB Connector cat5 Network Port RJ45 with magnetics

Product Details:

Place of Origin: DongGuan of China
Brand Name: DGKYD
Certification: RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Model Number: KRJ-CB009NL

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: Please contact us to get the latest price.
Packaging Details: Tray in Carton
Delivery Time: 10 days
Payment Terms: T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability: 100K pcs/day
Contact Now
Detailed Product Description
Product Name: Very Low Profile RJ45 Connector Performance: 100BASE-TX

RJ45 PCB Connector , Network Port RJ45 with GOLD Plating

P/N:KRJ-CB009NL

Extra low frofile RJ45 PCB Connector cat5 Network Port RJ45 with magnetics



Physical

Durability (mating cycles max) 750
Inverted / Top Latch Yes
Jack Height 13.87mm
Keying to Mating Part Yes
Lightpipes/LEDs LEDs
Material - Metal Brass, Phosphor Bronze
Material - Plating Mating Gold
Material - Plating Termination Tin
Net Weight 8/g
Orientation Right Angle (Side Entry)
PCB Retention None
Packaging Type Tray
Panel Mount No
Pitch - Mating Interface 1.02mm
Pitch - Termination Interface 1.02mm
Plating min - Mating 0.381µm
Plating min - Termination 1.270µm
Ports 1
Positions / Loaded Contacts 8/8
Surface Mount Compatible (SMC) No
Temperature Range - Operating -40°C to +85°C
Termination Interface: Style Through Hole
Wire/Cable Type N/A

The Jack series integrates the high performance of DGKYD magnetics into industry standard connector designs. A complete line of Integrated RJ-45 connectors for 10BASE-T, 10/100BASE-TX, and Gigabit Ethernet. The result is an extremely robust, IEEE802.3 compliant solution. The complete FastJack series is UL60950 and EN60950 compliant.
